歐式電纜分接箱是近年來廣泛用于電力配網系統中的電纜化工程設備；它的主要特點是雙向開門、利用對接套管作為連接母排，具有長度小、電纜排列清楚、三芯電纜不需大跨度交叉等顯著優點。其所采用的電纜接頭符合DIN47636標準。一般采用額定電流630A螺栓固定連接式電纜接頭。

  European-style cable branch box apply widely to cabling engineering equipment in the cable distribution network system in recent years.it have main characteristic of two-way open the door.butt joint bushing as connection bus bar.it have the length short.cable permute clearly,Three core cable have significant advantages that need not large span cross.The cable joint measure up to DIK147636 standards,it "Ixed

connection type cable joint with the rated current 630 A bolt generally

適應環境Adapt to the environment

●環境溫度：最高氣溫+40℃，最低氣溫-30℃

Ambient temperature:maximum air temperature+40℃,mnimum air temperature -30℃

●風速：相當34m/s（不大干700Pa）

Wind speed: amount to 34m/s(no more than 700 pa)

●濕度：日相對濕度平均值不大于95%，月相對濕度平均值不大于95%

Relative humidity:day relative humidity of the average is not greater than 95%;

month relative humidity of the average is not greater than 95%

●防震：水平加速度不大于0.4m/s，垂直加速度不大干0.15m/s

Ouakeproof:level acceieration is not grater than 0.4m/s,
