產品特點Productfeatures
秉泰公司生產的美式電纜分接箱，以其優良的性能，規范化的設計，優美的外觀，廣泛應用于電纜配電網系統中的電纜化工程設備，在各大工業園區，居民小區，城市人口密集區，商業中心以及高層建筑等各種場所得到普遍認同。它以單向開門、橫向多通母排為主要特點，具有寬度小，組合靈活、全絕緣、全密封等顯著優點。按照額定電流一般可以分為600A主回路和200A支回路兩種。600A主回路采作旋入式螺栓固定連接；200A分支回路采用拔插式連接且可以帶負荷拔插。
ZHEJIANG BINGTAI ACCESSORIES OF CABLES CO., LTD product American-style branch box.it have excellent performance. normalized design. graceful apperance, it apply widely to cabling engineering equipment of cable power distribution network system, There is wide recognition that our prodicts in the various big industrial park. residential communityurban population centre、business center and high-rise buildings etc. it have main feature that one-way to open the door. lateral multipass bus bar, it have significant advantages that small width. flexible combinationfull insulation. omnisel etc.according to current rating, can be div|ded int0 600A major loop and 200A loop generally. Fix and connect 600A maior loop with screw-in type bolt 200A branch loop adopt pull and plug type connection and can charged pull and plug
適應環境Adapt to the environment
●環境溫度：最高氣溫+40℃，最低氣溫-30℃
Ambient temperature: maximum air temperature+40℃, minimum air temperature-30℃
●風速：相當34m/s（不大于700Pa）
Wind speed: amount to 34m/s(no more than 700 pa)
●濕度：日相對濕度平均值不大于95%：月相對濕度平均值不大于95%
Relative humidity:day relative humidity of the average is not greater than 95%:
month relative humidity Of the average is not greater than 95%
●防震：水平加速度不大于0 4m/s，垂直加速度不大于0.15m/s
Quakeproof:level acceleration is not grater than 0.4m/s,
vertical acceleration ls not greater than 0.15m/s
●安裝地點傾斜度：不大干3°
Installation site slope: it is not more than 3°
●安裝環境：周圍空氣應不受腐蝕性、可燃性氣體、水蒸氣等明顯污染，安裝地點無劇烈震動
installation envlronment:Ambient air should not be clearly polluted by corrosive.
combustible gases. water vapor, installation site is not violent vibration
洼：訂購本產品超出上述條件規定時，請與本公司協商。
Note: When ordering the product is beyond the above conditions required,Please negotiate with our company
